Download Patch Panel Visio Stencils
A full set of Visio® stencils for Patch Panels are now available to download online on the HellermannTyton website. The stencils can be used to plan the layout of panels in a rack or data centre and then the software can produce a Bill of Materials (BOM) based on the design, detailing part numbers and quantities of the items required.
Click here to download HellermannTyton Patch Panel Visio Stencils (ZIP, 3.44MB)
About HellermannTyton Patch Panels
HellermannTyton's range of patch panels extends from Category 6A, Category 6 through to Category 5e and Category 3 voice solutions. The range includes 1U and 2U modular flat (FTP available as either fixed and sliding) and angled panels.
New Pod - 4 Port and 6 Port in Cat6A, Cat6 and Cat5e
The new Pod available in Cat6A, Cat6 and Cat5e for both UTP and FTP, is an important step in being able to install and deliver reliable and resilient network connections in work area applications.
Category 6A UTP System
At the centre of the HellermannTyton Category 6A UTP solution is the GST jack.
FDN 16 Port Base
The FDN 16 Port Base from HellermannTyton has been developed to address demand for higher port fibre density counts and larger cables.
