3mm Corridor Clips
Art.-No. 857-41166 | FFO-C3CLIPS/100 Details

  • Fire-resistant 1200°C
  • BSEN 50200 120 minutes fire time
  • DIN 4102-12 DIN 90 minutes fire time
  • Corrosion Resistant & UV Stable
  • Sold in packs of 100
Show more
Cable ∅ max 3mm
Colour White (WH)
Content Box of 100 x 3mm fire-resistant NANO Clips
Material Spring Steel (SpS)
PART DESCRIPTION FFO-C3CLIPS/100
Product Family Indoor Fibre Management Accessories
Product Group 3mm Corridor Clips
Short Description 3mm Corridor Clips
Technical Description These corridor cable clips (NanoClip™) are barely visible when fitted and provide a neat and tidy finish. They are designed to fit fibre optic cables and all other small diameter cables. Safe and 18th Edition compliant, they are CE & CA certified. 90 & 120 minute fire resistant, they meet the BSI and DIN classifications and are suitable for indoor use. Corrosion resistant and UV stable, they can be used outdoor. Manufactured in spring steel, the barbed design grips better for a secure fixing on the wall. No plus, screws or washers are needed. The corridor cable clip supports a maximum tensile load of up to 3.7kg depending on the type of substrates. Hole diameter will vary depending on the type of substrates: 3mm for softer substrates like plaster or plasterboards and 3.5-4.5mm for harder substrates like timber, masonry or concrete. A spacing of 300mm between each cable clip is recommended. Three easy step installation: drill a hole in your wall (16mm depth), insert the cable into the open side of the clip and push the closed side of clip into the wall.
Type FFO-C3CLIPS/100
