B Length with Basket
Art.-No. 857-00655 | FDNTB-BXBCD41 Details

  • Maximum 288 fibre splice capacity
  • 58 round ports and 1 oval port
  • Fibre storage basket for loop through applications
  • Supplied with 24 NZDF SE-A Trays fitted with 2 x 3A (Green) splice protector inserts
  • Maximum 12 splices per tray
  • Splitter accommodation
  • Cablelok compatible for all port sizes
  • Quick release cover
  • Optional flash test valve and/or grounding feed-through
Show more
Colour Black (BK)
Content FDN 59 Port Base
B-Length Cover (Dome)
Quick Release Clamp
Sealing ’O’ Ring
Fibre Storage Basket
Tray Support Frame
Anchor Fixing Kit (3)
24 x NZDF SE-A 3A Splice Trays
Tray Tool
Hook and Loop Tray Securing Straps
Transportation Tubing
Tubefix – Tube to Tray Securing Blocks
Hook and Loop Management Ties
Isopropyl Alcohol Wipes
Desiccant
Installation Guide
Marker Kit
Red Marker 1 – 25
Green Marker 1 – 25
Cover Type B
Method of Sealing Cablelok, Heatshrink
Package Content packed in kit
PART DESCRIPTION FDNTB-BXBCD41
Port L, T, S, B, R
Port count 1, 2, 4, 2, 52
Product Family B Length with Basket
Product Group FDN 59 Port Tubed Closure
Qty Trays 24
Splice Capacity 288
Technical Description The FDN 59 Port B Length closure with basket is supplied with a Polypropylene base. The base configuration of 58 round ports and 1 oval port covers a cable diameter range of 1.7 – 29.0mm when using Cablelok mechanical seals and 6.0 – 35.0mm when using heatshrink. The mounting system is manufactured from Grade 304 stainless steel and the backplane is an aluminium extrusion which manages 24 NZDF SE-A 3A Splice Trays. The tubed closure and the position of the mounting system allows for ease of access and traceability of the fibre on to the trays and the basket provides storage space for the storage of fibre loops. The trays are white which makes it easy to see the colour of the fibre elements as they are routed through the fibre management system.
Type of Tray Hellipse NZDF SE-A
Variant Outdoor FTTx Enclosures
Length (mm) 663mm
Width D1 312mm
Width D2 222mm
Country of Origin GB
Customs Number 85176200
GTIN-13 / EAN 5022660112683
ETIM 7.0 Key EC000762
