Cablelok R60OV 5.4 x 3.0mm x1
Art.-No. 857-50248 | CABLELOK-R60OV-01 Details

  • Cable range coverage from 1.7mm to 9.5mm
  • Multi-hole versions available to allow 2 cable drops from the same port
  • Multi-hole cable range coverage from 1.7mm – 2.0mm (R10D), 2.0mm - 3.0mm (R15D) and 3.8mm – 4.8mm (R30D)
  • Port closure plug available
  • Supplied in multiples of 1 and 10
  • Supplied with installation lubricant sachets
Show more
Colour Black (BK)
Content 1 x CABLELOK-R60OV, 1 x Lubricating Wipes
Material Chloroprene Rubber (CR)
PART DESCRIPTION CABLELOK-R60OV-01
Pack Cont. 1pcs.
Package Content packed in bag
Port R
Port count 1
Product Description HellermannTyton’s patented Cablelok mechanical seal enables fast safe cable installation, providing a highly repeatable and consistent seal between the cable and the closure port with excellent non-leak performance. Tested to in excess of 6m head of water, the Cablelok does not rely on the skill and experience of the engineer to achieve the required seal, whilst installation times are typically reduced by up to 90%.
Product Family R Port Series
Product Group R Port Cablelok
Short Description Cablelok R60OV 5.4 x 3.0mm x1
Technical Description The R60OV Port Cablelok is a mechanical seal manufactured from external grade flexible polychloroprene designed to be used with the range of HellermannTyton dome closures. The R60OV cablelok provides a seal for an oval cable with a diameter of 5.4mm x 3.0mm and is compatible with the RocTM Drop cable.
Type CABLELOK-R60OV-01
Variant Round - R
Country of Origin GB
Customs Number 40169300
GTIN-13 / EAN 5022660199752
Packaging 1 - Height (m) 0.381m
Packaging 1 - Length (m) 0.254m
Packaging 1 - Qty 1
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0
Packaging 1 - Weight (kg) 0.5kg
ETIM 7.0 Key EC000879
ETIM 8.0 Key EC000879
ETIM 9.0 Key EC000879
